Product Details:
|
| Type: | Patch Antenna | VSWR At CF Max: | 1.5 |
|---|---|---|---|
| Polarization Model: | RHCP | Operating Temperature: | -40~+85°c |
| Selling Units: | Single Item | Certification: | ROHS , REACH Compliance |
| Cable: | RF1.13 Or Others | Connector: | IPEX Or Others |
| Application: | Car-Navigation , Tablet , Drone Etc | Gain: | 2.0 DBi |
Item code: JCDZ-004-651540
5G communication, mobile communication base station, satellite communication, cordless telephone, global positioning system (GPS ,GLONASS , BEIDOU ,RFID , SDARS , IRNSS , GALEILLO ,WIFI patch antennas), radio frequency control, digital mobile TV, Internet of Things and other communication, aerospace fields.
Technical indicators:
|
project |
content |
|
Antenna size |
15*15*4 |
|
Number of feed needles |
1 |
|
center frequency |
699-960,1710-2170,2300-2700 MHz |
|
increase |
2dBi |
|
Polarization mode |
right handed elliptically polarized wave |
|
impedance |
50Ω |
|
standing-wave ratio |
≤2 db |
|
operating voltage |
3~10(V) |
|
Working temperature |
-25℃~+75℃ |
|
storage temperature |
-40℃~+85℃ |
|
humidity |
40%~95% |
1. Q : Are you manufacturer ?
A : Yes , we are manufacturer and product more than 10 years .
2.Q : Can you provide free samples ?
A : Yes , The sample is free .
3.Q: What is your MOQ ?
A : 1 pcs , We accept smaller quantity but price is higher .
4.Q : What is your production time for bulk order ?
A : 7-10 days , According to order quantity .
